This Petroleum System study is a quantitative investigation of the Campos Basin, based on detailed geological, geophysical and geochemical information of all its systems, but mainly on its exceptional well-recognized overcharged system: the Lagoa Feia-Carapebus (!). It was sourced from lacustrine-saline organic shales and predominantly preserved in widespread turbidite reservoirs of the Carapebus Formation.

In this study High-Resolution Geochemical Technology (HRGT) was applied in 228 selected oil samples and 39 wells (for source rocks) aiming to identify and characterize the petroleum systems of the Campos Basin. The integration of all data allowed the distinction and mapping of oil families and their respective source rock distributions. In addition, source-rock age and depositional environment, thermal evolution, degree of thermal oil-to-gas cracking and biodegradation were also characterized. Also, parameters controlling oil quality and possible migration pathways from source rock to trap were discussed by means of 2D basin modeling of two regional cross-sections representing the main tectonic-sedimentary aspects of the geologic evolution of Campos Basin.

A substantial part of this study contains a detailed section on electrofacies and lithofacies characteristics of Oligocene and Miocene deep-water reservoirs, which required a large set of core samples, logs and seismic sections from some production fields and data from adjacent wells. It is a very useful geophysical and sedimentological framework to address some of the most important reservoirs of the basin.

Full references of all images are listed in the reports
